Acoustic Firestop Mortar
Fire Barrier F360 Class
THERMOLOCK Acoustic Firestop Mortar is a new generation construction plaster designed for acoustic and fire insulation. It is classified as A1 non-combustible according to EN standards and provides F360 class fire resistance. F360 class defines the highest level of protection for fire-retardant insulation materials.
The product is specially formulated for interior and exterior applications requiring superior fire safety and acoustic insulation. It has a breathable structure due to the perlite and inorganic components it contains, while never allowing fire or smoke formation. It is also suitable for use on different surfaces.
Advantages
Fire resistance ≤ 360 minutes
CE-certified
High acoustic insulation
Easy to install
Smooth finish
- Suitable for most surfaces
Application
1. The substrate should be clean, free of dust, oil, and weak particles.
2. Mix 20 kg powder with approximately 15–16 liters of clean water using a low-speed mixer.
3. Apply manually with a trowel or by machine spraying.
4. For multilayer applications, allow the first layer to dry before applying the next.
5. Protect the surface from direct sun, wind, and frost during curing.
Areas of Application
– Wall and ceiling coverings
– Cable trays, ladders, cables and cable bundles
– Multilayer pipes with or without insulation
– Gas pipes, drinkpipes, meter box penetrations
– The outer surfaces of the arc furnaces
– Chimney linings of iron and steel factories
Applicable Surface Areas
– Concrete
– Wood
– Plastic
– Glass
– Metal
– Gypsum board
Sustainability
Thermolock KF-S 012 is made from natural, inorganic materials and is free from VOCs, fibres, and harmful chemicals.
It helps reduce CO₂ emissions, improves fire safety, and extends the lifespan of building structures.
Primer Application
Primer use is required for surfaces other than concrete.
The product to be used as primer is Thermolock Adhesion Enhancing Transition Primer.
Please refer to the product’s technical data sheet or product documentation for its use.
Storage
– Store in a dry, closed place on pallets.
– Do not stack more than 10 bags.
– When stored this way, it has a shelf life of 12 months.
Safety
Avoid contact with skin and eyes
– Wear protective gloves and goggles during application.
– Non-flammable and non-toxic. Classified as a non-hazardous cement-based material.
– For detailed health information, please refer to the MSDS document.
Technical Specifications
| Property | Value |
|---|---|
| Color | Grey |
| Binder | Special cementitious formulation |
| Density (Bulk) | 450 ± 5% kg/m³ |
| Thermal Conductivity (λ) | 0.060 W/m·K (±10%) |
| Fire Classification | A1 Non-Combustible (EN 13501-1) |
| Fire Resistance | F360 (360 minutes) |
| Sound Insulation | Up to 56 dB (depending on system) |
| Water Vapor Permeability | High (breathable) |
| Water Resistance | Hydrophobic additives (upon request) |
| Compressive Strength | CS III (≥ 3.5 N/mm²) |
| Adhesion Strength | ≥ 0.3 N/mm² |
| Workability Time | 120 minutes |
| Drying Time | 24–48 hours (depending on layer thickness) |
| Mixing Water Requirement | 15–16 L per 20 kg bag |
| Application Thickness | 10–30 mm (per layer) |
| Consumption | 4.5–5.0 kg/m² per 10 mm layer |
| Shelf Life | 12 months in dry conditions |
| Application Temperature Range | +5 °C to +35 °C |
| Application Type | Machine or steel trowel |
| Packaging Type | 20 kg |
